Adding ordered path to your ternary plot

Adding paths between points in a ternary space can help illustrate transitions or sequences in the data.

In the example of instant-runoff voting in Australian Federal Election, these paths can be used to illustrate the change in preference distribution between rounds of voting in one electorate. This vignette shows how to add paths to both 2D and high-dimensional ternary plots.

2D ternary plot

Take the example of the 2022 Australian Federal Election, we would like to take a look at the changes in preference distribution across rounds in three electorates: Higgins, Monash, and Melbourne.

Input data is already in a ternable-friendly format, with each row representing the preference distribution in one round of voting in one electorate.

aecdop22_widen <- prefviz:::aecdop22_widen
input_df <- aecdop22_widen |>
   filter(DivisionNm %in% c("Higgins", "Monash", "Melbourne"))
head(input_df)
#> # A tibble: 6 × 6
#>   DivisionNm CountNumber ElectedParty   ALP   LNP Other
#>   <chr>            <dbl> <chr>        <dbl> <dbl> <dbl>
#> 1 Higgins              0 ALP          0.285 0.407 0.309
#> 2 Higgins              1 ALP          0.285 0.407 0.307
#> 3 Higgins              2 ALP          0.288 0.409 0.303
#> 4 Higgins              3 ALP          0.292 0.411 0.297
#> 5 Higgins              4 ALP          0.294 0.416 0.290
#> 6 Higgins              5 ALP          0.300 0.448 0.252

# Create ternable object
tern22 <- as_ternable(input_df, ALP:Other)

For 2D ternary plots, adding ordered paths is straightforward using the stat_ordered_path() function, and providing the order_by aesthetic. This is equivalent to geom_path() when you pre-order your data points in the order you want them to be connected.

In this case, we want to connect the points in the order of round (order_by = CountNumber) for each electorate (group = DivisionNm).

# The base plot
p <- get_tern_data(tern22, plot_type = "2D") |>
  ggplot(aes(x = x1, y = x2)) +
  add_ternary_base() +
  geom_ternary_region(
    aes(fill = after_stat(vertex_labels)),
    vertex_labels = tern22$vertex_labels,
    alpha = 0.3, color = "grey50",
    show.legend = FALSE
  ) +
  geom_point(aes(color = ElectedParty)) +
  add_vertex_labels(tern22$simplex_vertices) +
  scale_color_manual(
    values = c("ALP" = "red", "LNP" = "blue", "Other" = "grey70"),
    aesthetics = c("fill", "colour")
  )

# Add ordered paths
p + stat_ordered_path(
  aes(group = DivisionNm, order_by = CountNumber, color = ElectedParty),
  size = 0.5
)

It’s interesting to see such a close win of ALP in Higgins (red line) since the result only flipped in the last round. Meanwhile, wins in Monash and Melbourne were consistent with first preference.

High-dimensional ternary plot

Let’s take a look at Monash and Melbourne in 2025 election, but this time we will use a high-dimensional ternary plot with 5 parties: ALP, LNP, GRN, IND, and Other.

Unlike 2D ternary plots, we need to group and order the data before plotting by providing the group and order_by arguments when creating ternable object. Since this data is already ordered by round in the input data frame, we just need to provide the grouping variable (DivisionNm).

aecdop25_widen <- prefviz:::aecdop25_widen
input_df2 <- aecdop25_widen |>
  filter(DivisionNm %in% c("Monash", "Melbourne"))
head(input_df2)
#> # A tibble: 6 × 8
#>   DivisionNm CountNumber ElectedParty   ALP   GRN   LNP Other    IND
#>   <chr>            <dbl> <chr>        <dbl> <dbl> <dbl> <dbl>  <dbl>
#> 1 Melbourne            0 ALP          0.313     0 0.198 0.439 0.0495
#> 2 Melbourne            1 ALP          0.316     0 0.199 0.444 0.0408
#> 3 Melbourne            2 ALP          0.321     0 0.201 0.434 0.0444
#> 4 Melbourne            3 ALP          0.326     0 0.212 0.408 0.0538
#> 5 Melbourne            4 ALP          0.343     0 0.236 0.421 0
#> 6 Melbourne            5 ALP          0.530     0 0     0.470 0

# Create ternable object
tern25 <- as_ternable(input_df2, ALP:IND, group = DivisionNm)

Adding paths in a high-dimensional ternary plot is made possible by the edges arguments in display_xy(). Therefore, besides simplex edges, we need to provide the data edges to the edges argument. This can be done by setting include_data = TRUE in get_tern_edges().

# Add colors
party_colors <- c(
  "ALP" = "#E13940",    # Red
  "LNP" = "#1C4F9C",    # Blue
  "GRN" = "#10C25B",    # Green
  "IND" = "#F39C12",    # Orange
  "Other" = "#95A5A6"   # Gray
)

color_vector <- c(rep("black", 5),
  party_colors[input_df2$ElectedParty])

edges_color <- c(rep("black", nrow(tern25$simplex_edges)),
  party_colors[input_df2$ElectedParty])

# Animate the tour
animate_xy(
  get_tern_data(tern25, plot_type = "HD"),
  col = color_vector,
  edges = get_tern_edges(tern25, include_data = TRUE),
  edges.col = edges_color,
  obs_labels  = get_tern_labels(tern25),
  axes = "bottomleft"
)
