Getter functions to extract components from ternable object for ternary plots

Source: R/ternable_getters.R
ternary_getters.Rd

Performs additional transformations on ternable object components, making it ready for both 2D ternary plot with ggplot2 and high-dimensional ternary plots with tourr.

Usage

get_tern_data(ternable, plot_type = c("2D", "HD"))

get_tern_edges(ternable, include_data = FALSE)

get_tern_labels(ternable)

Arguments

ternable

A ternable object created by as_ternable().

plot_type

Only in get_tern_data(). Character string specifying the type of plot to be drawn. Either "2D" for a 2D ternary plot or "HD" for a high-dimensional ternary plot.

include_data

Logical. Only in get_tern_edges(). If TRUE, return data edges, along with simplex edges. If FALSE, only return simplex edges.

Value

  • get_tern_data(): A data frame as input for ggplot2 or tourr.

    • If plot_type = "2D", the data frame augments the original data, with its ternary coordinates. Used as input data for ggplot2.

    • If plot_type = "HD", the data frame combines ternary coordinates of original data with those of simplex vertices (without vertex labels). Used as input data for tourr.

  • get_tern_edges(): A matrix of simplex edge connections for drawing the simplex boundary.

    • If include_data = FALSE, the matrix contains only the simplex edges. Equivalent to ternable$simplex_edges.

    • If include_data = TRUE, the matrix combines the simplex edges with the data edges. Used when you want to draw lines between the data points.

  • get_tern_labels(): A character vector containing vertex labels. Used as vertex labels for tourr, via argument vertex_labels.

Details

These functions are designed to work together for creating animated tours of high-dimensional ternary data:

  • get_tern_data() provides the point coordinates

  • get_tern_edges() provides the simplex structure

  • get_tern_labels() provides labels that align with the data rows

See also

as_ternable() for creating ternable objects

Examples

if (FALSE) { # \dontrun{
library(ggplot2)
# Create a ternable object
tern <- as_ternable(election_data, ALP:Other)

# Use with tourr (example)
tourr::animate_xy(
 get_tern_data(tern, plot_type = "HD"),
 edges = get_tern_edges(tern),
 obs_labels  = get_tern_labels(tern),
 axes = "bottomleft")

# Use with ggplot2 (example)
ggplot(get_tern_data(tern, plot_type = "2D"), aes(x = x1, y = x2)) +
  add_ternary_base() +
  geom_point(aes(color = ElectedParty))
} # }
